High-power LED airport floodlights are made of aerospace-grade aluminum alloy, with power options ranging from 500W to 2000W and a luminous efficacy of 130lm/W. They provide uniform, glare-free professional lighting for aviation operation areas such as aprons and boarding gates. The IP66 protection rating ensures stable operation in harsh environments such as heavy rain, high temperatures, and salt spray. Energy consumption is reduced by more than 60% compared to traditional metal halide lamps, and the lifespan exceeds 50,000 hours, significantly reducing airport operating costs.
Product Details: What are LED Airport High-Power Apron Lights?
LED Airport Floodlights are high-power lighting devices specifically designed for aviation operations such as airport aprons, aircraft parking areas, and maintenance hangars. They utilize high-brightness LED light sources combined with precision optical lenses to achieve long-distance, wide-area, uniform illumination, meeting the stringent requirements for light intensity and uniformity in aviation safety operations.
Solving the four major pain points of traditional airport lighting
Pain Point 1: Uneven Illumination, Creating Safety Hazards in Dark Areas.
Traditional metal halide lamps suffer severe light decay, with illuminance decreasing by more than 30% after six months of use. This results in dark areas on the tarmac, affecting the safety of ground staff working at night and increasing the risk of aircraft collisions.
- Solution: IAN Lighting uses imported CREE/OSRAM LED chips, combined with professional-grade optical design, achieving a luminous efficacy of over 130 lm/W and an illuminance uniformity of over 0.7, fully meeting ICAO and FAA technical standards. Multiple beam angles are available, allowing for flexible configuration based on the parking position layout to ensure zero dark area coverage.
Pain Point 2: High Energy Consumption, Electricity Costs Account for a Large Portion of Operating Costs
Traditional 1000W metal halide lamps consume over 1100W in actual use and require a ballast. A single lamp consumes over 4,800 kWh annually, and airport lighting electricity costs account for 15%-20% of operating costs.
- Solution: 1000W LED floodlights replace traditional metal halide lamps, saving over 60% in energy. Based on 12 hours of operation per day, a single lamp saves over 2,600 kWh annually, with a payback period of only 2-3 years. Intelligent dimming automatically adjusts brightness according to flight schedules, further reducing energy consumption.
Pain Point 3: High Failure Rate and High Maintenance Costs.
Metal halide lamps have a lifespan of only 3,000-5,000 hours, requiring frequent replacements. Furthermore, the installation height of these lamps is 15-30 meters, necessitating the use of aerial work platforms and significant manpower for maintenance, resulting in maintenance costs of several thousand yuan per instance.
- Solution: The housing is made of aerospace-grade die-cast aluminum alloy, with a double anti-corrosion treatment of anodizing and powder coating, and has passed a 5,000-hour salt spray test. The IP66 protection rating effectively resists heavy rain and sandstorms, while the IK08 impact resistance rating can withstand vibrations and airflow impacts generated during aircraft operation. LED lifespan exceeds 50,000 hours, extending maintenance cycles by 10 times.
FAQ
Q: How is heat dissipation handled in LED airport floodlights?
A: A finned heat dissipation structure combined with heat pipe technology is used to control the junction temperature below 75°C, ensuring minimal LED light decay. The surface temperature of the casing does not exceed 65°C to avoid the risk of burns.
Q: Can it withstand the high salt spray environment of coastal areas?
A: The casing is made of ADC12 aluminum alloy die-casting, with a surface treated by anodizing and outdoor polyester powder coating for double corrosion protection. It has passed the ASTM B117 standard 5000-hour salt spray test and is suitable for coastal airports.
Company Strength
Since 2007, IAN LED Lighting Factory has been dedicated to producing high-quality lighting products and serving over 150 countries. We always strive for excellence, aiming to supply the best quality products at reasonable prices, along with exceptional service, to win our customers’ hearts and trust.
For your project, we can provide free DIALux illumination simulations to create a customized lighting solution tailored specifically to your needs.
Contact us (rena@ianled.com) for the best suitable lighting solution you need.
